24W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter

Minimum Order Quantity : 1000PCS Price : Negotiable
Packaging Details : Color box Delivery Time : 5-8 working days
Payment Terms : Western Union, T/T,, L/C Supply Ability : 30k per day
Place of Origin: Made in China Brand Name: APS
Certification: CE(EMC/LVD), FCC, DOE,CEC,Engery Star Model Number: APS-PS1014

Detail Information

Model No: APS-PS1014 Product Name: Ac To 12v Dc Power Adapter 24w
Material: ABS&PC Fireproof Material Color: Black Or White Optional
Input: AC100V-240V Output: DC 12V 2A
Output Power: 24W MTBF: 5000 Hours
Burn In Test: 100% OEM&ODM: Acceptable
DC Connector: 2.5x0.7 / 3.5x1.35/ 4.0x1.7/5.5x2.1/5.5x2.5/mocro...... Key Function1: Universal AC Adapter For Mopping Machine/Humidifier
Key Function2: Country Adapter Plugs For Router/Massage Chair/Camera Etc. Key Function3: Switching Power Supply For Speaker/ HUB /video/IP Camera....
High Light:

24W AC TO 12V DC Power Adapter

,

12V 2A Switching Mode Power Adapter

,

12V 2A Universal AC DC Power Adapter

Product Description

Ac To 12v Dc Power Adapter 12v 2a Switching Mode Power Adapter Us Eu Uk Aus Plug Universal Ac Dc Power Adapter



Overview



AC 100V-240V 50/60Hz Input / 12Vdc 0-2000mA 24Watt Output / 6 Ft (1.8m) Power Cable. Level VI Energy Efficiency (Save 15%-20% Electricity Charge than Level V) / UL cUL FCC PSE TUV RoHS Safety Certificates Approved / 2 Years Warranty / Anti-interference Magnetic Ring to avoid EMI (Electromagnetic Interference) / Short Circuit & Over Voltage & Current Protection / 18Awg Power Wire / Exceed 10 years Lifespan / Low Fever / No Noise / High Quality Shockproof Retail Packing Box.This PSU will adjust the output current (2 A Max) accordingly to different devices, so it is a prefect replacement for all 12Volt 0-2Amp power supplies. (See Image-5 to Avoid Wrong Purchase ). (Should be 12 V & not exceed 24 W) : LED Strip Lights / Cable Modem / Router / Electronic Piano Keyboard / DVR NVR Surveillance System / Security CCTV Camera / Infrared IR Array Illuminator / Portable Radio / Computer PC Case Fan / Motor / Arduino PCB Design / Computer Speakers / Digital Photo Frame / External Hard Drive / Foot Back Neck Shoulder Massager / Fresh Water Bilge Air Pump / And Other 12 Vdc Devices.



Specifications



nput Input voltage AC 100~240V
Variation Frequency 50-60Hz
Input frequence 50~60Hz
Output Output voltage 12v
Output current 2A
Output power 24W
Input plug types EU/ US /UK /AUS /South Korea /South African Plugs
Out plug types DC jack, XLR, JST, Cigar Lighter, Alligator Clips,Viation Plug, Din Plug.etc
DC jack size 5.5*2.1mm, 5.5*2.5mm, 3.5*1.35mm, 3.5*1.0mm, 4.0*1.7mm, 2.5*0.7mm .etc
Safety protection Over voltage protection 120% min
Over current protection 120% min
Short circuit protection auto recovery
Over hot protection auto recovery
Electronic characteristics Operating Temperature -40~50°C
Storage Temperature -40 to +85 °C
Humidity 10%~95%RH
Efficiency 80%
Ripple And Noise Output voltage 1%, Ripple&Noise≤120mv
Turn-on Delay Time 3 second max
Overshoot at Turn-on 10% max when turn on or off
AC leakage Current 0.25mA max at AC 240V voltage
Load Regulation ±5%
Line Regulation ±5%
High-Voltage test Primary to secondary: 3 kV / 5mA 60S
Drop Test 0.75m drop test, 6 times
Burn-In Test 100% load, 5hours
Application CD/DVD,MP3/MP4,Digital camera,Comunication Terminals Etc
Safe Certificate CE ROHS
Manufacturer Advanced Product Solution Technlogy Co ltd



Features



1. High efficiency, low loss, energy saving and environmental protection circuit design;With over voltage, over current,

overload, short circuit protection;

2. Beautiful and elegant products, the shell adopts high temperature resistance and flame retardant, ultrasonic welding,

safe and reliable use;

3. Very small output interference, stable output voltage, can better extend the service life of external appliances;

4. Full power, good anti-interference performance, small dc ripple;

5. Low operating temperature and long service life of power supply;

6. Wide input voltage range, 100-240v, in line with global standards;

7. Good insulation, 100% vacuum impregnation of high-frequency transformer;

8. Full-load high-temperature burning machine, 100% aging test, low defect rate;

9. Input plugs from different countries are available;

10. Moisture-proof and dustproof;



24W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 024W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 124W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 224W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 324W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 424W AC TO 12V DC Power Adapter 12V 2A Switching Mode Power Adapter 5
